1475

Ball Valve, Mini - Female x Female

Quality:

Dual sealing system allows valve to be operated in either direction making installation easier. No metal-to-metal moving parts. No maintenance ever required. Handle clearly shows ball position. Silicone-free lubricant on all seals. Chrome plated brass ball for longer life. Each valve is seal tested for maximum safety

Features:

  • Body: One piece drawn sand blasted brass body with an extreme compact design
  •     ◦ Finest brass according to EN 12164 specification
  •     ◦ Patent n. 7011-B/89
  • Thread: ISO 7/1, BS 21 BSPT Taper
  • Stem: Blowout-proof brass stem with FPM O-ring
  • Handle: Reinforced nylon wedge handle removable with valve in service
  • Seals: Pure PTFE self-lubricating seats with flexible-lip design
  • Working Pressure: 30 Bar (450 PSI)
  • Operating Temperature: -20°C (-4°F) to + 120°C (+248°F)

Downloads

  Name Download File type
Ball Valve, Mini - Female x Female
Datasheet-Mini-Valves.pdf 808 KB
.pdf
